Flutter – How to Notch FloatingActionButton in BottomAppBar

Verified Solution Tested on Flutter 3.47.7 • Dart 3.13.5

Flutter – How to Notch FloatingActionButton in BottomAppBar screenshot

Flutter – How to Notch FloatingActionButton in BottomAppBar screenshot For advanced action button setups, see how to handle adding multiple floating action buttons and customizing FloatingActionButton shapes and locations.

Updated Flutter Example

SDK: Flutter 3.47.7 • Dart 3.13.5 Verified on Flutter 3.47.7 (Stable)

Updated Flutter Example

Material 3 Docked FloatingActionButton with Circular Notch

Key Implementation Details & Modern Differences:

CircularNotchedRectangle Cradle: Uses CircularNotchedRectangle() with notchMargin: 6.0 on BottomAppBar to create a smooth circular cutout for the docked button.
FloatingActionButtonLocation: Applies FloatingActionButtonLocation.centerDocked to position the FAB seamlessly centered along the top edge of the navigation bar.
Material 3 Circle Shape: Explicitly specifies shape: const CircleBorder() to ensure the FAB adheres to the circular notch geometry in Material 3.

Updated Flutter Example Code

import 'package:flutter/material.dart';

void main() {
  runApp(const MaterialApp(home: ModernNotchedBottomAppBarDemo()));
}

class ModernNotchedBottomAppBarDemo extends StatefulWidget {
  const ModernNotchedBottomAppBarDemo({super.key});

  @override
  State<ModernNotchedBottomAppBarDemo> createState() =>
      _ModernNotchedBottomAppBarDemoState();
}

class _ModernNotchedBottomAppBarDemoState
    extends State<ModernNotchedBottomAppBarDemo> {
  int _actionCount = 0;

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('Notched BottomAppBar Demo')),
      body: Center(
        child: Text(
          'FAB Activations: $_actionCount',
          key: const Key('counter-text'),
          style: Theme.of(context).textTheme.headlineSmall,
        ),
      ),
      floatingActionButton: FloatingActionButton(
        shape: const CircleBorder(),
        onPressed: () {
          setState(() => _actionCount++);
        },
        child: const Icon(Icons.add),
      ),
      floatingActionButtonLocation: FloatingActionButtonLocation.centerDocked,
      bottomNavigationBar: BottomAppBar(
        shape: const CircularNotchedRectangle(),
        notchMargin: 6.0,
        child: Row(
          mainAxisAlignment: MainAxisAlignment.spaceBetween,
          children: [
            IconButton(icon: const Icon(Icons.menu), onPressed: () {}),
            IconButton(icon: const Icon(Icons.search), onPressed: () {}),
          ],
        ),
      ),
    );
  }
}
